Setting up a Receiver for

Step 1. Click Edit and Select Receivers

Next Step

Previous Step

Top of Page

Step 2. Click the New button to add a new Receiver or Click Edit to edit an existing Receiver

Next Step

Previous Step

Top of Page

Step 3. Setup the Wireless Receiver as shown

First, enter a meaningful name for the person carrying the Receiver (Pager or Cell Phone)

Next Step

Previous Step Top of Page

Step 4. Setup the Wireless Receiver as shown

Next, enter "pager " for the Receiver's ID.
Next Step

Previous Step Top of Page

Step 5. Setup the Wireless Receiver as shown

Finally, select Pass Word Paging - Internet SMTP for the Messaging Service and click OK .
Note: The name of the Messaging Service may differ between here and your InfoRad software. So look for keywords in the name of the service that match like PCS (for cell phones) or Pagers, E-mail, SMTP, SNPP, etc.

Otherwise, if Pass Word Paging - Internet SMTP - or similar - does not already exist, you can click the Add button to add it, only if needed.

Previous Step Top of Page

Step 6. Adding a new Messaging Service

Enter Pass Word Paging - Internet SMT for the name of the Messaging Service No password is required

Enter for the Max Message Length

It is common to leave 30 seconds as the timeout period and leave Log messages to this service unchecked.

Select send messages via

Once you have verified that all information is entered correctly, Click OK.

Previous Step

Top

Step 7. Continue Adding or Click OK

Once all Receiver(s) are entered, Click the OK button for the Listing of Receivers window to accept the newly added Receiver(s).

Otherwise, You can continue adding new Receivers by clicking on the New button and continue back from Step 3.

Previous Step

Top of Page

Step 8. DOUBLE CHECK YOUR MESSAGING SERVICE: Click Edit and Select Messaging Services

Previous Step

Top of Page

Step 9. Select the appropriate Messaging Service (under the Name column) and Click the Edit button

Select the appropriate Messaging Service (under the Name column) and Click the Edit button

Previous Step

Top of Page

Step 10. Verify the Messaging Service information and Click OK

Enter Pass Word Paging - Internet SMT for the name of the Messaging Service No password is required

Enter for the Max Message Length

It is common to leave 30 seconds as the timeout period and leave Log messages to this service unchecked.

Select send messages via

Once you have verified that all information is entered correctly, Click OK.
